HP Indigo 8000 digital label press – roll to roll 7 colours from 2015

HP Indigo 8000 digital label press – roll to roll 7 colours from 2015

Manufacturer: HP Indigo

Type: Indigo 8000
Year of manufacturing: 2015

Working width: 330 mm

Technical specifications

Speed: 197 ft/min in 4-color mode

262 ft/min in Enhanced Productivity Mode

812 dpi at 8 bit, addressability: 2438 x 2438 dpi HDI (High Definition Imaging) 175, 180, 196, 210 lpi
12.25 x 38.58 in (special marks complete print width format to 12.59 in)
0.5 to 18 pt.

Pressure-sensitive label stock, paperboard, and unsupported films Max. width: 13.39 in / Min. width: 7.87 in

Input roll max. diameter: 39.37 in Core inside diameter:
Standard: 3 in
Optional: 6 in

Max. roll weight: 595 lb
Enables easy on-demand treatment of substrates
27.56 in max. roll diameter

HP SmartStream IN120 Labels and Packaging Print Server and Color Engine, Powered by Esko

Length: 493.4 in, Width: 94.5 in, Height: 82.7 in

21,089 lb (including inline priming unit)

Cyan, magenta, yellow, and black

White, white for sleeves, premium white, fade resistant yellow, fade resistant magenta

Cyan, magenta, yellow, black, orange, and violet

Cyan, magenta, yellow, black, orange, violet, and green

HP IndiChrome Ink Mixing System (IMS) for spot color creation using CMYK as well as orange, violet, green, reflex blue, rhodamine red, bright yellow, and transparent

Supports PANTONE PLUS®, PANTONE MATCHING SYSTEM®, PANTONE GoeTM

HP Professional PANTONE Emulation Technology using CMYK on-press; HP IndiChrome on-press; HP IndiChrome Plus on-press; HP IndiChrome off-press (IMS) for achieving up to 97% of the PANTONE® color range.

Enables three-color EPM printing
Dual mode inline finishing connectivity kit, flexible packaging packer arm support in rewinder,

HP SmartStream Labels and Packaging VDP Tools, Powered by Esko
HP SmartStream Labels and Packaging Prepress Tools, Powered by Esko

Simplex and duplex capability
