ALS 204 Labeling Solution for Side Labeling
High-performance industrial system optimized for precise side labeling applications.
Description
With this application, labels between 10 – 106 mm width (material width incl. backing paper max. 110 mm) can be applied on products. The surface of the products needs to be flat to secure the smooth application of labels. Paper and stiff PE label materials can be used. The maximum apply speed is 40 m/min. The support stand with vertical and horizontal lead screws enables flexible integration onto a conveyor. The product start sensor has to be connected to the M12 plug on the ALS.
Important Benefits
- Flexible integration in your product line
- Attractive price-performance ratio
- Fast and durable for demanding applications
- High apply speed – up to 40 m/min
- Material width up to 110 mm
- Accurate label positioning
- Easy vertical and horizontal adjustment of the ALS by means of the lead screws
Main Specifications ALS 204
| Dispensing speed: | Up to 40 m/min |
| Material width incl. backing paper: | 10 – 110 mm |
| Label length: | 5 – 600 mm |
| Label roll diameter: | 300 mm |
| Data Interfaces: | RS 232C, Ethernet, USB |
